Output
|
Output power capacity
|
600Watts / 1.0 kVA
|
Max Configurable Power (Watts)
|
600Watts / 1.0 kVA
|
Nominal Output Voltage
|
120V
|
Output Frequency (sync to mains)
|
50/60Hz +/- 3 Hz
|
Topology
|
Line Interactive
|
Waveform type
|
Stepped approximation to a sinewave
|
Output Connections
|
(4) NEMA 5-15R (selector_surgetitle)
(4) NEMA 5-15R (Battery Backup)
|
Transfer Time
|
8ms typical : 12ms maximum
|
Input
|
Nominal Input Voltage
|
120V
|
Input frequency
|
50/60 Hz +/- 3 Hz (auto sensing)
|
Input Connections
|
NEMA 5-15P
|
Cord Length
|
6ft ( 1.83meters )
|
Input voltage range for main operations
|
88 - 148V
|
Number of Power Cords
|
1
|
Maximum Input Current
|
12.0A
|
Batteries & Runtime
|
Battery type
|
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
|
Typical recharge time
|
8hour(s)
|
Replacement Battery
|
APCRBC123
|
Expected Battery Life (years)
|
3 – 5
|
RBC Quantity
|
1
|
Communications & Management
|
|
Interface Port(s)
|
USB
|
Control panel
|
Multi-function LCD status and control console
|
Audible Alarm
|
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
|
Surge Protection and Filtering
|
Surge energy rating
|
354Joules
|
Data Line Protection
|
Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector), Coaxial cable for CATV/SATV/modem/Audio-Video (coax connector)
|
Filtering
|
Full time multi-pole noise filtering :5% of IEEE surge let-through : zero clamping response time: instantaneous
|
Physical
|
Maximum Height
|
9.84inches ( 250mm , 25.0cm )
|
Maximum Width
|
3.94inches ( 100mm , 10.0cm )
|
Maximum Depth
|
15.04inches ( 382mm , 38.2cm )
|
Net Weight
|
23.58lbs. ( 10.72kg )
|
Shipping weight
|
25.74lbs. ( 11.7kg )
|
Shipping Height
|
13.27inches ( 337mm , 33.7cm )
|
Shipping Width
|
8.86inches ( 225mm , 22.5cm )
|
Shipping Depth
|
19.17inches ( 487mm , 48.7cm )
|
Color
|
Black
|
Master Carton Units
|
1.0
|
Pallet Dimensions
|
46inches
|
Pallet Weight
|
865.22lbs.
|
Units per Pallet
|
16.0
|
SCC Codes
|
1073130427878 5
|
Environmental
|
Operating Environment
|
32 - 104 °F ( 0 - 40 °C )
|
Operating Relative Humidity
|
0 - 95 %
|
Operating Elevation
|
0-9842ft ( 0-2952.6meters )
|
Storage Temperature
|
-15 - 45 °C
|
Storage Relative Humidity
|
0 - 95 %
|
Storage Elevation
|
0-49212ft ( 0-14763.6meters )
|
Audible noise at 1 meter from surface of unit
|
45.0dBA
|
Online thermal dissipation
|
67.6BTU/hr
|
Warranty
|
2 years
|
