APC 1100VA

APC 1100VA

Rs. 6,480.00
Rs. 6,480.00
Sale Sold out
Taxes included.

ITEM DETAILS: APC 1100VA

FEATURES:

  • Audible alarms Provides notification of changing utility power and UPS power conditions
  • • Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
  • • Automatic Voltage Regulation (AVR) Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
  • • Boost and Trim Automatic Voltage Regulation (AVR) Eliminates voltage fluctuations as a source of AV signal degradation and component power-supply stress.
  • • Cold-start capable Provides temporary battery power when the utility power is out.

TECHNICAL DETAILS:

Output

Output power capacity

660Watts / 1.1 kVA

Max Configurable Power (Watts)

660Watts / 1.1 kVA

Nominal Output Voltage

230V

Topology

Line Interactive

Maximum Output Current

10

Output Connections

(2) India 2/3-pin 6A (selector_surgetitle)

(3) India 2/3-pin 6A (Battery Backup)

Input

Nominal Input Voltage

230V

Input frequency

47 - 63 Hz

Input Connections

Indian/South African BS 546A

Cord Length

1.48meters

Input voltage range for main operations

175 - 295V

Input voltage adjustable range for mains operation

160 - 286V

Number of Power Cords

1

Batteries & Runtime

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Included Battery Modules

1

Typical recharge time

10hour(s)

Replacement Battery

APCRBC113

Expected Battery Life (years)

2 – 4

RBC Quantity

1

Communications & Management

Control panel

LED status display with On Line : On Battery : Replace Battery and Overload indicators

Audible Alarm

Alarm when on battery : distinctive low battery alarm : configurable delays

Surge Protection and Filtering

Surge energy rating

441Joules

Data Line Protection

Analog phone line for phone/fax/modem/DSL (RJ-11 connector)

Filtering

Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height

222mm , 22.2cm

Maximum Width

132mm , 13.2cm

Maximum Depth

356mm , 35.6cm

Net Weight

11.0kg

Shipping weight

13.5kg

Shipping Height

310mm , 31.0cm

Shipping Width

244mm , 24.4cm

Shipping Depth

450mm , 45.0cm

Color

Charcoal

Master Carton Dimensions (Length x Width x Height)

310mm

Master Carton Units

1.0

Master Carton Weight

13.5

Units per Pallet

40.0

SCC Codes

1073130425013 2

Environmental

Operating Environment

0 - 40 °C

Operating Relative Humidity

0 - 95 %

Operating Elevation

0-3000meters

Storage Temperature

-5 - 45 °C

Storage Relative Humidity

0 - 95 %

Storage Elevation

0-15000meters

Audible noise at 1 meter from surface of unit

45.0dBA

Online thermal dissipation

180.0BTU/hr

Warranty

1 year





Product features

Materials and care

Merchandising tips

View full details
