Code Name
|
Sandy Bridge
|
Essentials
|
Vertical Segment
|
Desktop
|
Processor Number
|
i5-2400S
|
Status
|
End of Life
|
Launch Date
|
Q1'11
|
Expected Discontinuance
|
Q1'2013
|
Lithography
|
32 nm
|
Performance
|
# of Cores
|
4
|
# of Threads
|
4
|
Processor Base Frequency
|
2.50 GHz
|
Max Turbo Frequency
|
3.30 GHz
|
Cache
|
6 MB SmartCache
|
Bus Speed
|
5 GT/s DMI
|
TDP
|
65 W
|
Supplemental Information
|
Embedded Options Available
|
No
|
Memory Specifications
|
Max Memory Size (dependent on memory type)
|
32 GB
|
Memory Types
|
DDR3 1066/1333
|
Max # of Memory Channels
|
2
|
Max Memory Bandwidth
|
21 GB/s
|
ECC Memory Supported ‡
|
No
|
Graphics Specifications
|
Processor Graphics <sup><small>‡</small></sup>
|
Intel® HD Graphics 2000
|
Graphics Base Frequency
|
850 MHz
|
Graphics Max Dynamic Frequency
|
1.10 GHz
|
Intel® Quick Sync Video
|
Yes
|
Intel® InTru™ 3D Technology
|
Yes
|
Intel® Flexible Display Interface (Intel® FDI)
|
Yes
|
Intel® Clear Video HD Technology
|
Yes
|
# of Displays Supported ‡
|
2
|
Device ID
|
0x102
|
Expansion Options
|
PCI Express Revision
|
2.0
|
Max # of PCI Express Lanes
|
16
|
Package Specifications
|
Sockets Supported
|
LGA1155
|
Max CPU Configuration
|
1
|
T<sub>CASE</sub>
|
69.1°C
|
Package Size
|
37.5mm x 37.5mm
|
Low Halogen Options Available
|
See MDDS
|
Advanced Technologies
|
Intel® Turbo Boost Technology
|
2.0
|
Intel® vPro™ Technology ‡
|
Yes
|
Intel® Hyper-Threading Technology ‡
|
No
|
Intel® Virtualization Technology (VT-x) ‡
|
Yes
|
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
|
Yes
|
Intel® VT-x with Extended Page Tables (EPT) ‡
|
Yes
|
Intel® 64 ‡
|
Yes
|
Instruction Set
|
64-bit
|
Instruction Set Extensions
|
SSE4.1/4.2, AVX
|
Idle States
|
Yes
|
Enhanced Intel SpeedStep® Technology
|
Yes
|
Thermal Monitoring Technologies
|
Yes
|
Intel® Fast Memory Access
|
Yes
|
Intel® Flex Memory Access
|
Yes
|
Intel® Identity Protection Technology ‡
|
Yes
|
Security & Reliability
|
Intel® AES New Instructions
|
Yes
|
Intel® Trusted Execution Technology ‡
|
Yes
|
Execute Disable Bit ‡
|
Yes
|
Warranty
|
3 Years
|
