Code Name
|
Ivy Bridge
|
Essentials
|
Vertical Segment
|
Desktop
|
Processor Number
|
i3-3220
|
Status
|
Launched
|
Launch Date
|
Q3'12
|
Lithography
|
22 nm
|
Performance
|
# of Cores
|
2
|
# of Threads
|
4
|
Processor Base Frequency
|
3.30 GHz
|
Cache
|
3 MB SmartCache
|
Bus Speed
|
5 GT/s DMI
|
TDP
|
55 W
|
Supplemental Information
|
Embedded Options Available
|
Yes
|
Conflict Free
|
Yes
|
Memory Specifications
|
Max Memory Size (dependent on memory type)
|
32 GB
|
Memory Types
|
DDR3 1333/1600
|
Max # of Memory Channels
|
2
|
Max Memory Bandwidth
|
25.6 GB/s
|
ECC Memory Supported ‡
|
No
|
Graphics Specifications
|
Processor Graphics <sup><small>‡</small></sup>
|
Intel® HD Graphics 2500
|
Graphics Base Frequency
|
650 MHz
|
Graphics Max Dynamic Frequency
|
1.05 GHz
|
Intel® Quick Sync Video
|
Yes
|
Intel® InTru™ 3D Technology
|
Yes
|
Intel® Flexible Display Interface (Intel® FDI)
|
Yes
|
Intel® Clear Video HD Technology
|
Yes
|
# of Displays Supported ‡
|
3
|
Device ID
|
0x152
|
Expansion Options
|
PCI Express Revision
|
2.0
|
PCI Express Configurations ‡
|
up to 1x16, 2x8, 1x8 & 2x4
|
Package Specifications
|
Sockets Supported
|
FCLGA1155
|
Max CPU Configuration
|
1
|
Thermal Solution Specification
|
2011C
|
T<sub>CASE</sub>
|
65.3°C
|
Package Size
|
37.5mm x 37.5mm
|
Low Halogen Options Available
|
See MDDS
|
Advanced Technologies
|
Intel® Turbo Boost Technology
|
No
|
Intel® vPro™ Technology ‡
|
No
|
Intel® Hyper-Threading Technology ‡
|
Yes
|
Intel® Virtualization Technology (VT-x) ‡
|
Yes
|
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
|
No
|
Intel® VT-x with Extended Page Tables (EPT) ‡
|
Yes
|
Intel® 64 ‡
|
Yes
|
Instruction Set
|
64-bit
|
Instruction Set Extensions
|
SSE4.1/4.2, AVX
|
Intel® My WiFi Technology
|
Yes
|
Idle States
|
Yes
|
Enhanced Intel SpeedStep® Technology
|
Yes
|
Thermal Monitoring Technologies
|
Yes
|
Intel® Identity Protection Technology ‡
|
Yes
|
Security & Reliability
|
Intel® AES New Instructions
|
No
|
Secure Key
|
No
|
Intel® Trusted Execution Technology ‡
|
No
|
Execute Disable Bit ‡
|
Yes
|
Anti-Theft Technology
|
Yes
|
Warranty
|
3 Years
|
